Delta DVP-20PM

5 Applied Instructions and Basic Usage
2. Input pins/Output pins
Input pin
Name Function
Data
type
Setting value Time when a value is valid
Axis
Motion axis
number
WORD
DVP20PM00D:
K1~K2
DVP20PM00M:
K1~K3
The value of the Axis input pin is valid
when there is a transition in the
Execute input pin’s signal from low to
high.
Execute
Motion is started
when there is a
transition in the
Execute input
pin’s signal from
low to high.
BOOL True/False -
Distance1
Relative distance
for which the first
motion moves
DWORD
K-2,147,483,648~
K2,147,483,647
The value of the Distance1 input pin
is valid when there is a transition in
the Execute input pin’s signal from
low to high.
Velocity1
Target speed of
the first motion
DWORD K1~K2,147,483,647
The value of the Velocity1 input pin is
valid when there is a transition in the
Execute input pin’s signal from low to
high.
Distance2
Relative distance
for which the
second motion
moves
DWORD
K-2,147,483,648~
K2,147,483,647
(If the value of the
Distance1 input pin is
a positive value, the
value of the
Distance2 input pin
must be a positive
value. If the value of
the Distance1 input
pin is a negative
value, the value of
the Distance2 input
pin must be a
negative value.)
The value of the Distance2 input pin
is valid when there is a transition in
the Execute input pin’s signal from
low to high.
Velocity2
Target speed of
the second
motion
DWORD K1~K2,147,483,647
The value of the Velocity2 input pin is
valid when there is a transition in the
Execute input pin’s signal from low to
high.
Output pin
Name Function
Data
type
Time when there is
a transition in an
output pin’s signal
from low to high
Time when there is a transition in an
output pin’s signal from high to low
Done
The execution of
the motion
control function
block is
complete.
BOOL
 There is a
transition in the
Done output pin’s
signal when
motion is
complete.
 There is a transition in the Done
output pin’s signal from high to low
when there is a transition in the
Execute input pin’s signal from
high to low.
 If the Execute input pin is set to
False when motion is complete,
the Done output pin will be set to
False in the next cycle.
