U60 Diagnostic Ultrasound System User Manual Operation
- 96 -
To edit the worksheet:
Move the trackball to the text box and edit the worksheet. Press OK to save.
To add images to the report:
Press Image in the worksheet dialog box to add at most four images to the report.
Press or button or press the drop-down box on the bottom of the screen to
view the images stored in current Storage device, and check the box to select the
currently displayed image. The screen will show you how many images have been added, for
example, indicates there are two images added. Maximum four images can be added
into the report. Press to exit image adding.
To print a graph/text worksheet:
Press Print in the worksheet after connecting a graph/text printer.
To save a PDF worksheet:
1. Press Save PDF in the worksheet, the system displays Save PDF report dialog box;
2. Select the destination drive and folder, or press New Folder to create a folder for storing PDF
reports, and modify the file name; otherwise, the report will be saved to the default folder
with a default file name.
3. Press OK to save the PDF report to the designated folder, or press Esc to give up.
6.8. Comment Function
The comment library is for positions and anatomical structures.
NOTE:
1. The entered text is in upper case by default.
2. The comments are in different colors under active/inactive status. To preset the
comment colors, press Set up>System Preset.
To add a comment:
To add a comment by using the keyboard:
1. Press Comment, and there is a cursor “І” displayed in the image area for annotating;
2. Enter text by using the keyboard;
3. Press Set or Enter to complete the comment.
