EDAN U60 - Peripheral Connections

U60 Diagnostic Ultrasound System User Manual Installation Instructions
- 22 -
WARNING
Do not touch the pin of the probe connector.
CAUTION
Do not plug in or pull out the connector when the device is activated. This is to avoid
uncontrollable damage to the probe and the main unit.
NOTE:
Once the probe is connected to the main unit, please do not reinstall it frequently. This is
to avoid poor contact between the probe and the main unit.
4.3.3. Peripheral Connections
Video connections are located on the left panel of the U60.
WARNING
1. Accessory equipment connected to the analog and digital interfaces must be certified
according to the respective IEC/EN standards (e.g., IEC/EN 60950 for data
processing equipment and IEC/EN 60601-1 for medical equipment). Furthermore, all
configuration shall comply with the valid version of the standard IEC/EN 60601-1.
Therefore, anybody, who connects additional equipment to the signal input or output
connector to configure a medical system, must make sure that it complies with the
requirements of the valid version of the system standard IEC/EN 60601-1. If in doubt,
consult our technical service department or your local distributor.
2. Parts and accessories used must meet the requirements of the applicable IEC/EN
60601 series safety standards, and/or the system configuration must meet the
requirements of the IEC/EN 60601-1 medical electrical systems standard.
3. Connecting any accessory (such as an external printer) or other devices (such as the
computer) to this equipment makes a medical system. In that case, additional safety
measures should be taken during installation of the system, and the system shall
provide:
a) Within the patient environment, a level of safety comparable to that provided by
medical electrical equipment complying with IEC/EN 60601-1;
b) Outside the patient environment, the level of safety appropriate for non-medical
electrical equipment complying with other IEC or ISO safety standards.
4. Parts and accessories must be connected to the I/O ports designated in Figure 4-7.
For example, only the supplied or recommended USB device can be connected to
the USB ports; DO NOT connect telephone line to the network port; DO NOT connect
earphone to the footswitch port or remote port.
