U60 Diagnostic Ultrasound System User Manual Abdominal Measurements and Calculations
- 118 -
measurement.
Reference Section 6.5.1Generic Measurements in B Mode.
3. After the measurement, the result of gallbladder will be displayed in the measurement result
window.
7.1.3. Pancreatic
1. In the abdominal measurement menu, roll the trackball to highlight Pancreatic, select Panc
Duct/ Panc Head/ Panc Body/ Panc Tail from the submenu, and then press Set.
2. Measure Panc Duct/Panc Head/Panc Body/Panc Tail by the method of distance measurement.
Reference Section 6.5.1Generic Measurements in B Mode.
3. After the measurement, the result of pancreatic will be displayed in the measurement result
window.
7.1.4. Spleen
1. In the abdominal measurement menu, roll the trackball to highlight Spleen, press Set.
2. Measure three pieces of data: SPLEEN-L, SPLEEN-W, and SPLEEN-H by the method of
distance measurement.
Reference Section 6.5.1Generic Measurements in B Mode.
3. After the three measurements, the result of spleen will be displayed in the measurement result
window.
7.2. Abdominal Report
After the abdominal examination, the system generates an abdominal worksheet.
1. Select the desired probe model and the exam mode Abdomen/ Abd Difficult/ Aorta.
2. In B mode, after application measurements press Report to open Abdominal worksheet, as
shown below:
