Save image parameter preset:
1. After the image parameter adjustments, press Save Preset Data key (user-defined key
F1/F2/F3/F4).
2. Press OK in the “Save current image parameters data?” dialog box.
3. Press OK in the “Overwrite the current exam preset data?” dialog box to save the image
parameter preset to the current exam mode; Or press Cancel, and enter a new exam name in
the “Add new Exam mode” dialog box to save the image parameter preset to the new exam
mode.
6.5. Generic Measurements and Calculations
Generic Measurement & Calculation Items
Distance, Area (Ellipse/Trace), Volume (2-Axis/3-Axis), Ratio, Angle, and Histogram
Distance, Time, Slope and Hear Rate (two cycles)
Velocity, Heart Rate, Time, Acceleration, Resistance Index (RI), Pulsatility Index (PI) and
Auto Trace (auto trace is available only for PW mode)
Table 6-6 Generic measurement & calculation Items
Distance and circumference will be presented in mm or cm; area, in mm
2
, cm
2
,
or dm
2
; volume, in
mm
3
, cm
3
, dm
3
,
mL or L; time in ms or s, and heart rate in bpm, etc.
After entering B/ Color/ PDI/ PW/ CW/ M mode, press Caliper to activate the B/ Color/ PDI/
PW/ CW/ M mode generic measurement function, and the light will be on.
There is one type of mark in B mode measurement: “+”.
There are three types of marks in M mode measurement: “+”, big “+”, and a line.
The measurement results will be displayed in real-time. After measurement, the outcome is
displayed in measurement result window with a serial number. You can measure one to eight
groups of data. If you continue to measure, the earliest group will be automatically covered by the
newest one.
NOTE:
1. When you exit measurement status, or press EndExam/Clear, all the measurements
will be cleared.
2. During general measurement, press Backspace to delete the previous operation.
3. After a complete general measurement, press Backspace to erase a measurement at
a time.
