U60 Diagnostic Ultrasound System User Manual Operation
- 110 -
4. If the server is running normally, the current Cine images will be sent to the server.
5. The progress bar disappears after successful transmission.
To send a Cine File
1. Highlight the submenu Cine File, and then press Set.
2. The system displays the File Opening Dialog Box for selecting a cine file to be transmitted.
3. If the server is running normally, the selected file will be sent to the server.
4. The progress bar disappears after successful transmission.
CAUTION
1. When the file transmission to DICOM server fails the system will display the prompt
message"Fail to transmit!". In this case, it is recommnend to check the network
connection and do the transmission manually again.
6.13. Needle Guide Function
NOTE: Use proper disinfection technique at all times to perform a biopsy.
Always follow these basic precautions:
WARNING
1. Sterilize the needle guide before the first use and after each use.
2. Always handle transducers and needle guide adaptors with care. Do not use a
transducer or an adaptor if it has been dropped or struck against a hard surface until
it is inspected by an EDAN customer engineer.
3. The displayed needle guide pathway on the EDAN video monitor is intended for
reference during biopsy procedures. A variety of factors outside EDAN’s control, such
as changing tissue density, bending of the needle, off-axis pressure by the person
holding the transducer, may cause deflection of a needle outside of the displayed
video pathway even when the transducer, needle guide, and the system software are
all performing as intended and within manufacturing specification. The specialist
performing a biopsy procedure must be aware of potential external factors when
executing an invasive procedure.
4. The caliper must be placed along the needle path. If not, the displayed
measurements may be incorrect.
5. EDAN needle guides are designed and manufactured to attach firmly to designated
transducers and should not require excessive force to assemble or disassemble. If it
appears that excessive force or manipulation is required to assemble or disassemble
