U60 Diagnostic Ultrasound System User Manual System Control
- 52 -
.
3. Arrange the sequence of the associated exams: after the exams associated with the probe are
set, you can select an exam, and click on or to adjust the sequence of
it gradually.
4. Click on to confirm the modification, or click on to give up.
5.7.5. Exam Preset
Exam Preset is used to add exam mode and set the application associated with the probe.
Application types include abdomen, obstetrics, gynecology, pediatric, small parts, urology,
peripheral vascular, musculoskeletal, and cardiac.
Figure 5-13 Exam Preset Dialog Box
Operations:
To get a copy of the existing exam: Select the desired exam mode, and click on Copy. For
example, select the exam “PV Artery”, and press Copy to get “C PV Artery”, a copy of the
exam “PV Artery’. To rename the “C PV Artery” exam, click on Rename.
To delete an exam: Select a desired exam mode, click on Delete, the system displays a
To Next Page
