U60 Diagnostic Ultrasound System User Manual Peri. Vascular Measurements & Calculations
- 171 -
Reference Section 6.5.4 Generic Measurements in D Mode.
3. The results are displayed in measurement result window.
4. To begin a new Vert A measurement, repeat steps 1 through 3. You can measure a maximum
of one group of data.
13.1.5. UPPER
To measure UPPER:
1. In the PW-vascular measurement menu, select UPPER.
2. Measure UPPER by the method of D trace measurement.
Reference Section 6.5.4 Generic Measurements in D Mode.
3. The results are displayed in measurement result window.
4. To begin a new UPPER measurement, repeat steps 1 through 3. You can measure a maximum
of one group of data.
13.1.6. LOWER
To measure LOWER:
1. In the PW-vascular measurement menu, select LOWER.
2. Measure LOWER by the method of D trace measurement.
Reference Section 6.5.4 Generic Measurements in D Mode.
3. The results are displayed in measurement result window.
4. To begin a new LOWER measurement, repeat steps 1 through 3. You can measure a
maximum of one group of data.
13.2. Vascular Report
After finishing the vascular examination, the system generates a vascular worksheet.
1. Select the desired probe model and the exam mode Carotid / PV Artery/ PV Vein.
2. In PW mode, after application measurements press Report to open Vascular worksheet, as
shown below:
