U60 Diagnostic Ultrasound System User Manual Gynecology Measurements and Calculations
- 156 -
R. OV-L
R. OV-W
R. OV-H
Right Ovary Length
Right Ovary Width
Right Ovary Height
Distance (mm)
L.FO-Vol
Left Follicle Volume
(Left Follicle 1-4)
Vol(cm
3
)=π/6 ×D1(mm)×D2(mm)×D3(mm)/1000
L. FO-D1
L. FO-D2
L. FO-D3
Left Follicle Distance 1
Left Follicle Distance 2
Left Follicle Distance 3
Distance (mm)
R.FO-Vol
Right Follicle Volume
(Right Follicle 1-4)
Vol(cm
3
)=π/6 ×D1(mm)×D2(mm)×D3(mm)/1000
R. FO-D1
R. FO-D2
R. FO-D3
Right Follicle Distance 1
Right Follicle Distance 2
Right Follicle Distance 3
Distance (mm)
CX-L
Cervix Length
Distance (mm)
UT-L/CX-L
The ratio of Uterus Length
and Cervix Length
Distance (mm)
Table 10-1 Gynecology Measurement and Calculation Items in B Mode
10.1.1. UT
To measure UT:
1. In the B-gynecology measurement menu, roll the trackball to highlight UT and press Set.
2. Perform three measurements, UT-L, UT-W and UT-H by the method of distance
measurement.
Reference Section 6.5.1 Generic Measurements in B Mode.
3. After the three measurements are performed, the system calculates UT-V automatically, and
the result of UT and UT-V will be displayed in the measurement result window. You can
measure a maximum of one group of data.
10.1.2. Endo
To measure endometrium:
1. In the B-gynecology measurement menu, roll the trackball to highlight Endo and press Set.
2. Measure Endo by the method of distance measurement.
Reference Section 6.5.1 Generic Measurements in B Mode.
3. The result of Endo will be displayed in the measurement result window. You can measure a
maximum of one group of data.
