U60 Diagnostic Ultrasound System User Manual Operation
- 113 -
BGK-CR10UA
Structures:
Installation and Use Steps:
1. Place an appropriate amount of gel on transducer surface, and insert transducer into the
sheath.
2. Loosen the locking knob to open the clamp of bracket. Attach the bracket to the transducer
by aligning the locating markers on the bracket and the transducer.
3. Properly secure the clamp of bracket with the locking knob. Ensure the backet is firmly
attached, and then place the biopsy needle into the needle guide path.
