U60 Diagnostic Ultrasound System User Manual Cardiac Measurements and Calculations
- 140 -
MAVO1
Aortic Valve Volume Opened,
beginning
Distance (mm)
MAVO2
Aortic Valve Volume Opened,
ending
AA
Aortic Amplitude
LVMW
Left Ventricular Muscle Weight
LVMW (g) =1.04* ({IVSTd (cm)+LVIDd (cm)+LVPWd
(cm)}
3
-LVIDd
3
(cm)
3
)-13.6
LVMWI
Left Ventricular Muscle Weight
Index
LVMWI (No unit) = LVMW/BSA
A/E
The ratio of CA to CE
A/E (No unit) = CA (mm)/CE (mm)
LAD/AOD
Left Atrium Diameter / Aortic
root Diameter
LAD/AOD (No unit) = LAD (mm) / AOD (mm)
QMV
Mitral Valve Flow
QMV (mL) = 4*DEV (cm/s)*DCT (s)
Table 9-3 Other Measurement Items
4. Calculation items:
Label
Description
Method
EDV
End Diastolic Volume
EDV (mL) = LVIDd
3
(mm
3
)/1000
CUBE formula
ESV
End Systolic Volume
ESV (mL) = LVIDs
3
(mm
3
)/1000
CUBE formula
SV
Stroke volume
SV (mL) = EDV (mL)-ESV (mL)
CO
Cardiac Output
CO (L/min) = SV (mL) × HR (bpm)/1000
EF
Ejection fraction (M mode)
EF (No unit) = SV (mL)/ EDV (mL) × 100%
FS
Fractional Shortening
FS (No unit) =[ {LVIDd (mm)- LVIDs (mm)}/ LVIDd
(mm) ]x 100%
SI
Stroke Index
SI (No unit)= SV (mL)/ BSA (m
2
)
CI
Cardiac Index
CI (No unit)= CO (L/min)/ BSA (m
2
)
MVCF
Mean Velocity Circumferential
Fiber Shortening
MVCF (No unit)= { LVIDd (mm)- LVIDs (mm)}/ {LVIDd
(mm) × ET (ms)/1000}
BSA
Body Surface Area (m
2
)
Calculate by to the selected formula
LVMW
Left Ventricular Muscle Weight
LVMW (g)=1.04*[{IVSTDd (cm)+LVIDd (cm) +
LVPWd
3
(cm)}
3
-LVIDd
3
(cm)
3
]-13.6
