EPSON Stylus Pro 9000
Adjustments 118
CHECK NOZZLE
Use this function to verify that the all nozzles are firing ink. If you notice missing
lines or gaps, you can run the cleaning operation from this menu.
1. Make sure "Adj: Check Nozzle" appears on the LCD and press the Enter
button.
2. Load paper if not already loaded and replace any low or empty ink
cartridges if detected. The printer prints the following check pattern:
The pattern includes the following colors from left to right: black, cyan,
magenta, yellow, light magenta, and light cyan.
3. When the check pattern finishes printing, "Nozzle Check End" appears on
the LCD. If the pattern printed all six colors properly with no missing dots or
lines, press the Enter button to end this adjustment procedure. Otherwise,
press the SelecType button to start the cleaning cycle.
"x" = B or C, for Head B or Head C
*
00000-x-ID1: AAAAAA
0
*
0000-x-ID1: AAAAAA
00
*
000-x-ID1: AAAAAA
000
*
00-x-ID1: AAAAAA
0000
*
0-x-ID1: AAAAAA
00000
*
-x-SUM: AAAAAA
Press the [Enter] button if an
input error occurs.
Error Rank Input
When finished entering the Head C
ID, press the [Enter] button.
Cleaning
Enter Key
Please Set Ink
[Enter]
Insert ink cartridges
Press Paper Feed +/- to
select the value
Please Set Paper
Load paper.
Please Set Ink
Replace any low or empty ink
Printing Pattern
[SelecType]
[Enter]
End
adjustment
Nozzle Check End
Cleaning Standard
Print Adj. Pattern
