EPSON Stylus Pro 9000
Appendix 151
ASSEMBLING THE PRINTER BODY
1. Open the large box by cutting the center of the sealed tape and take out
the Accessory Box, two spindles and two styrol pads protecting the printer
body on the right and left.
2. Take out the four box panels, one on each side of the box and remove the
Documentation box.
W ARNING
When lifting or moving the printer body, use at least
4 people, since the printer weighs approximately
160 lb (74 kg).
When removing the large box, be sure that there is
enough space overhead (about 7 feet or 2 meters of
clearance is required).
To Next Page
