EPSON Stylus Pro 9000
Disassembly & Assembly 56
4.1.2 Tools
This section lists the tools necessary to disassemble or assemble the printer.
4.1.3 Screw List
The following table lists all the screws used in this printer.
Table 4-1. Necessary Tools
Tool Part Code Notes
(+) Phillips screwdriver
Regular, every-day
tools are OK, no
special tools needed
No. 1 and no. 2 sizes needed
(-) Standard screwdriver —
Needle-nosed pliers —
Tweezers —
Hex (Allen) wrench
• 1.5 mm (CR motor)
• 2.5 mm (PF motor and CR
belt)
• 4.0 and 5.0 mm for setting up
printer only
Table 4-2. Screws
Type Color Description
CP(W2)M3x6 black (+) Crosshead Pan, spring washer, flat washer
CP(W2)M4x12 silver (+) Crosshead Pan, spring washer, flat washer
CP(W2)M4x6 silver (+) Crosshead Pan, spring washer, flat washer
CP(W2)M4x12 black (+) Crosshead Pan, spring washer, flat washer
CP(W2)M3x8 silver (+) Crosshead Pan, spring washer, flat washer
CP(W2)M3x6 silver (+) Crosshead Pan, spring washer, flat washer
CP(W2)M4x5 silver (+) Crosshead Pan, spring washer, flat washer
CBF3x6 silver (+) Bind screw, flange
CPM2x4 silver (+) Crosshead Pan
CBM3x6 silver (+) Bind screw
Hex screw silver Six-sided hex screw, 1.5 and 2.5 mm
