EPSON Stylus Pro 9000
Troubleshooting 40
3.2.1 LCD Error Messages
When a part reaches the end of its useful life, an error code appears on the
printer’s LCD display. For example, MAINTENANCE REQ. 0100 appears on
the display to warn that the Waste Ink Pads are about 99% full. The printer
continues to print while this message appears. When the Waste Ink counter
determines that the Waste Ink Pads are completely full, the printer displays
SERVICE REQ. 00000100 and stops printing.
Error codes also alert the user to fatal errors and other printer problems. Refer
to the tables below to determine the meaning of each code.
Table 3-1. Error Message List for Service Technicians
Error Code Description Refer to
Maintenance
Req. nn
0100
Waste Ink pads is almost full (less than 1%
remaining)
page 41
Service Req.
nnnnnnnn
00000100 Waste Ink pads must be replaced
page 41
00000101 Ink Tube worn out
page 41
00010000 PF motor encoder check error
page 41
00010001 PF motor out of step
page 41
00010002 PF motor overcurrent
page 42
00010003 PF in-position time-out
page 42
00010004 CR motor encoder check error
page 42
00010005 CR motor out of step
page 42
00010006 CR motor overcurrent
page 43
00010007 CR in-position time-out
page 43
00010008 Servo interrupt watchdog time-out error
page 43
00010009 System interrupt watchdog time-out error
page 43
0001000A CR origin sensor malfunction
page 43
0001000C PG origin sensor malfunction
page 43
0001000D Cover sensor malfunction (00)
page 44
0001000E Cover sensor malfunction (01)
page 44
0001000F CR motor PWM output error
page 44
00010010 PF motor PWM output error
page 44
Service Req.
nnnnnnnn
00020000 NVRAM error
page 44
00020001 Internal RAM check error
page 44
00020002 SRAM check error
page 44
00020003 DRAM check error
page 44
0002000B Mail Box receiving error
page 44
10000004 CPU vector 4 - General illegal instruction
page 44
10000006 CPU vector 6 - Slot illegal instruction
page 44
10000009 CPU vector 9 - CPU address error
page 44
1000000A CPU vector 10 - DMAC/DTC address error
page 44
1000000B CPU vector 11 - Watchdog time-out error
page 44
100000”” CPU vector 32 to 63 - Wrong trap
page 44
Table 3-2. General Error Message List
Error Type Message Refer to
Warning Ink Low
page 45
Error
Paper Out
page 45
Load xxx Paper
page 45
Load Paper
page 45
Paper Jam
page 46
Cover Open
page 46
Paper Not Cut
page 46
Paper Not Straight
page 46
Reload Paper
page 47
Push Lever Down
page 47
Compartment Open
page 47
Ink Out
page 48
No Ink Cartridge
page 48
Remove Paper
page 48
Option I/F Error
page 48
Table 3-1. Error Message List for Service Technicians (continued)
Error Code Description Refer to
