EPSON Stylus Pro 9000
Adjustments 115
5.3.4 Adjustment Menu
The Adjustment menu allows you to make certain adjustments to the printer
mechanism and controls.
Table 5-7. Adjustment Menu Items
LCD Message Description
Cap Position
Adjustment
on
page 116
Sets the capping position (automatic adjustment)
Check Skew
on
page 117
Checks the skew (slant) of currently loaded paper
Input Rank (Printhead
ID) Adjustment
on
page 117
Lets you set the printhead ID
Check Nozzle
on
page 118
Prints a nozzle check pattern so you can see whether
printhead nozzles are clogged
B Head Slant/C Head
Slant Adjustment
(Head Angle)
on
page 119
Prints a test pattern to let you adjust the angle of Head B or
Head C (mechanical adjustment)
BC Head Slant
Adjustment (Head
Height)
on page 120
Prints a test pattern to let you adjust Head C to the same
height as Head B (mechanical adjustment)
Bi-D Adjustment
on
page 121
Prints test patterns to let you adjust vertical alignment
during bi-directional printing
Head LR Adjustment
(Head Gap Timing)
on
page 123
Prints test patterns to let you set the correct spacing
between the printheads
Flush Point Right and
Left Adjustment
on
page 124
Adjusts the flushing positions
Feed Adjustment
on
page 124
Prints a test pattern to let you verify that the paper feeding
distance is correct and adjust it if necessary
Top & Bottom (Margin)
Adjustment
on
page 125
Prints a test pattern to let you verify that the top, bottom,
and side margins are correct and adjust them if necessary
Rear Sensor Position
Adjustment
on
page 126
Prints a test pattern to let you verify that the distance from
the rear paper-edge is detected correctly and adjust it if
necessary
Test Print
on page 127 Prints either a nozzle check or a list of all adjustment
variables (parameters)
Clean Head (Drain Ink)
on page 127
Drains all ink from the printer by flushing the printheads and
ink delivery system
Counter Clear
on
page 128
Resets all counters in
Table 5-11
on page 128
When conducting on-site service or repairs, do not
select "Head Cleaning" as this requires a separate
head cleaning cartridge to work properly.
Select "Counter Clear" only when replacing the
Waste Ink Pads along with all replaceable parts of
Maintenance Assembly. See Maintenance
Procedures on page 67.
Unless otherwise indicated, you should not use
costly roll paper to print the test patterns in this
section. Use standard cut-sheet sizes, 11
×
17 inch or
larger. For adjustments that require a high degree of
precision (Bi-D and head angle adjustments), be sure
to use coated ink jet paper.
