EPSON Stylus Pro 9000
Disassembly & Assembly 57
4.1.4 Order of Disassembly
For efficient disassembly and assembly, refer to the following flowchart.
Figure 4-1. Disassembly Process Flowchart
Maintenance Cover Removal
on
page 58
Top Cover Removal
on page 70
Upper Paper Guide Removal
on
page 64
Left and Right Side Cover
Removal
on page 60
Front Cover Removal
on page 61
Lower Paper Guide Removal
on
page 63
Removing the Paper Release
Sensor
on page 81
Power Supply Board Removal
on
page 65
Removing the Carriage Home
Position Sensor and Encoder
on
page 82
Roll Cover Removal
on page 62
Replacing the Waste Ink Pads
on
page 67
Removing the Front Paper Sensor
on page 81
Replacing the Printheads
on
page 71
Main Board Removal
on page 66
Removing the Rear Paper Sensor
on page 80
Removing the Platen Gap
Adjustment motor
on page 78
Removing the Platen Gap Home
Position Sensor
on page 78
Removing the Paper Thickness
Sensor
on page 80
Removing the Cover open
Sensors
on page 79
Removing the PF Motor Assembly
on page 76
Maintenance Assembly Removal
& Disassembly
on page 69
Removing the Carriage Motor
Assembly
on page 75
To access these
parts, you need to
remove only the
Right
Side Cover
To access the Left I/L Switch, you also
need to remove the Upper Paper Guide
To access the Maintenance Assembly,
you also need to remove the Lower
Paper Guide and Right Waste Ink Box
To access the PF Motor, you also need
to remove the Lower Paper Guide
