EPSON Stylus Pro 9000
Appendix 147
 Paper Eject Tray (Cloth/ metal shafts are attached inside)
 Tray Hooks x 2 (one each for right and left)
 Pins x 2
 Hexagon (Allen) wrench x 2 (large: 5mm / small: 4mm)
 Bolts (4 kinds)
 For assembling the stand
8 bolts with hexa
g
on hole
(
M6 x 30
)
6 bolts with hexa
g
on hole
(
M6 x 10
)

For connecting the printer body and stand
2 washer bolts with hexa
g
on hole
(
M6 x 12
)
2 flan
g
e bolts with hexa
g
on hole
(
M6 x 12
)
LARGE BOX
The following parts are in the large box.
 EPSON Stylus Pro 9000 printer body
 2 Spindles for roll paper (for 2-inch diameter roll paper)
 Accessory Box
Ink Cartrid
g
es x 6
(
one for each color
)
Roll paper

Documentation Box (Guide Books and CD-ROM, etc.)
7.1.3 Unpacking and Assembly
FROM UNPACKING TO ASSEMBLING THE STAND
1. Remove the band connecting the large box and medium size box, and take
out the medium size box.
2. Open the medium size box and verify the contents. (See the previous
page.)
W ARNING
 It is recommended at least two people (four for
printer body) unpack and assemble the stand.
(Weight of stand: approximately 50 lb (22 kg) after
assembling.)
 Perform unpacking and assembly in a stable, open
place, about 12 × 12 ft (4 × 4 m).
 If possible, save the original packaging in case you
need to transport the printer in the future.
