7.6 Parts List
Table 7-12. Parts List
Block Name
Ref
No.
Part Code Description Qty
CASE BLOCK 180 1046615 LABEL,CAUTION;B 1
CASE BLOCK 181 1046617 LABEL,CUTER CHANGE;B 1
CASE BLOCK 182 1046619 LABEL,PAPER JAMING;B 1
CASE BLOCK 183 1046621 LABEL,CUT PAPER SET;B 1
CASE BLOCK 184 1046623
LABEL,ROLL PAPER
SET;B
2
CASE BLOCK 185 1046625
LABEL,PAPER LEVER SET
UP;B
1
CASE BLOCK 186 1046626
LABEL,TRANSPORT/
STRAGE,LIGHT;B
1
CASE BLOCK 187 1046628
LABEL,TRANSPORT/
STRAGE,LEFT;B
1
CASE BLOCK 188 1046633
LABEL,INK MODEL
NUMBER,LIGHT;B
1
CASE BLOCK 189 1046634
LABEL,INK MODEL
NUMBER,LEFT;B
1
CASE BLOCK 190 1046635
LABEL,CAUTION,STEEL
BELT;B
1
CASE BLOCK 191 1045247 LABEL,CUT POSITION 1
CASE BLOCK 192 1045248
LABEL,VALVE OPEN AND
SHUT;LIGHT
1
CASE BLOCK 193 1045249
LABEL,VALVE OPEN AND
SHUT;LEFT
1
CASE BLOCK 194 1046637
LABEL,PAPER EJECT
CLOTH SET;B
1
CASE BLOCK 195 1046639
LABEL,CAUTION,CUTER;
B
1
CASE BLOCK 196 1046641
LABEL,CAUTION PAPER
COVER;B
2
CONTROL
CIRCUIT BOAR
200 2029123 BOARD ASSY.,MAIN 1
CONTROL
CIRCUIT BOAR
201 2030185 SIMM,16M SET 1
PRINTER
MECHANISM
101 1044247 X REDUCTION BELT 1
PRINTER
MECHANISM
102 1044248 ROLL SUPPORT L,ASSY 2
PRINTER
MECHANISM
103 1044249 ROLL SUPPORT R,ASSY 2
PRINTER
MECHANISM
104 1044250 COVER SUPPORT ASSY 4
PRINTER
MECHANISM
105 2030086 PF MOTER PULLEY ASSY 1
PRINTER
MECHANISM
106 1044252 AIR SHIELD A 4
PRINTER
MECHANISM
107 1044253 AIR SHIELD B 4
PRINTER
MECHANISM
108 1044254 VACUUM FAN ASSY 3
PRINTER
MECHANISM
109 1044255 FAN DUCT 3
PRINTER
MECHANISM
110 1044256
VACUUM FAN 1 CABLE
ASSY
1
PRINTER
MECHANISM
111 1044257
VACUUM FAN 2 CABLE
ASSY
1
PRINTER
MECHANISM
112 1044258
VACUUM FAN 3 CABLE
ASSY
1
Table 7-12. Parts List (continued)
Block Name
Ref
No.
Part Code Description Qty
