EPSON Stylus Pro 9000
Adjustments 127
TEST PRINT
This function lets you print all the check patterns used in making adjustments
as covered in this chapter. It also lets you print a list of the current settings of all
the adjustments.
To print the list of adjustment variables, you need to enter the printer’s serial
number when prompted. The serial number is located on the back of the
printer, next to the power connector.
CLEAN HEAD (DRAIN INK)
This function allows you to drain the ink from the ink delivery system including
the printheads. Perform the Clean Head function before moving the printer.
Table 5-10. Printed Items in the Test Print
Item Description
Nozzle Check Prints all of the check patterns.
Adjustment Variables Prints a list of all adjustment settings.
Print: Nozzle Check
[Enter]
[Enter]
[SelecType]/
[Paper Source]
[SelecType]/
[Paper Source]
The printer prints the adjustment-
parameter list, ejects the paper, and
proceeds to next menu.
End
adjustment/
next menu
Printing Pattern
Printing Pattern
Print: Adj. Variable
No. X: PEG
* * * * * * * *
Print Adj. Pattern
Paper Feed +/-
X = "1"~"4"
*
= Serial number
CAUTION
After draining the ink and performing any necessary
operations such as moving the printer, be sure to
perform the initial ink charge as described in Cleaning
menu on page 128, or reset the initial ink charge flag
as described in Update
on page 129.
[Enter]
[Enter]
Adj Clean Head
Please Remove Ink
Please Lower InkLever
Please Remove Ink
Cleaning
Set Cleaning Jig
Press the Pause button
to quit this menu and
complete this operation.
[Pause]
Not applicable for
service purposes
Remove all ink cartridges.
Lower both ink set levers.
Perform ink drain operation.
