EPSON Stylus Pro 9000
Troubleshooting 53
Reload Paper — CN5 Printhead Board Paper Width Sensor
Service Req. 00010000 — (Error code doesn’t match problem) CN27 Main Board Left Cover Open
Service Req. 00010000 — (Error code doesn’t match problem) CN13 Relay Board Right Cover Open
Service Req. 00010000 — CN13 Main Board PF Encoder
Service Req. 00010000 — CN14 Main Board Relay Board CN5
Service Req. 00010000 — CN18 Main Board PF Motor
Service Req. 00010004 — CN17 Main Board CR Motor
Service Req. 00010004 — Carriage slams right CN2 Printhead Board CR Linear Encoder Sensor
Service Req. 00010004 — Carriage slams right
CN6 ribbon cable
(white)
Relay Board Printhead Board
Service Req. 0001000A — CN4 Printhead Board Home Position Sensor
Service Req. 0001000C — CN17 Relay Board Platen Gap Origin Sensor
Service Req. 0001000C — CN18 (light blue cable) Relay Board Platen Gap Motor
Service Req. 0001000C — CN24 Main Board Relay Board CN4
Service Req. 0001000F — Carriage doesn’t move out of home position CN9 Relay Board CR Lock Solenoid
Table 3-4. Connector-Related Errors (continued)
LCD errors LED errors Symptom
Connector
description
From To
