25.1.2 Testing (the analog loop)
Fig. 8: Testing the analog loop
♦
Enter the number of the analog loop to be tested and press the
Select
function key.
♦
Enter the number of the desired function (3 = Testing) or select the menu options
Test operation
with the cursor keys and press the
Function
key
!
An analog loop in test operation will not signal an alarm in the case of an event !
The Function
Testing
is not carried out when ...
♦
the analog loop is switched off.
♦
the analog loop module is defective.
Testing an analog loop
The test operation must be carried out individually for each analog loop or detector zone. The
simultaneous testing of several analog loops/detector zones is impossible.
By this menu point, the selected analog loop (including all detectors and esserbus
®
transponders)
or single detector zones in the analog loop are tested for the following functions:
♦
Malfunctions of one or more detectors / esserbus
®
transponders.
♦
Malfunction of the switch-on control (SOC) by automatic detectors.
♦
Conformance of the addresses with the Customer data programming
(if necessary, the detector data is automatically updated).
♦
Conformance of the analog loop wiring with the Customer data programming.
♦
Conformance of detector types and external wiring with the Customer data programming.
C
ommissioning / Servicing
Primary loop / transfer route
Primary loop : 121
Escape
Function
1 Switch on / reset
2 Switch off
3 Test
4 Replace detector
