Fire Alarm Computer 8000C / M
Page 49
6 Installation Instructions
The terminal assignment and wiring illustrated in these installation instructions refer exclusively to the
facilities of the operating system software for the Federal Republic of Germany [D].
Operation of the fire alarm control panel 8000C/M is governed by the national version of the operating
system software used and the country version programmed in the customer data.
6.1 Standards, guidelines and instructions for installation
S
The fire alarm panel may only be installed in a dry, clean room with controlled access and
appropriate lighting. The environmental conditions must comply with IEC 721-3-3:1994, class
3k5.
S
The panel must be mounted on a flat surface using appropriate hardware (screws and dowels).
Avoid mechanical stressing. It may only be commissioned after correct mounting on a wall or
other mounting surface of sufficient strength to support the weight of the unit.
S
Avoid strong electric or magnetic fields as well as mechanical influences. This applies
especially to the presence of fluorescent lighting or energy cabling in the close vicinity of the
panel, its components and the associated cabling. Do not mount on vibrating, unstable
surfaces such as light partitioning walls.
S
Do not install the system in places where adverse conditions prevail. Parts and components of
the system may only be installed in or led through locations which allow compliance with DIN
VDE 0800.
S
Connect the FE (functional earth) and PE (protective earth) terminals of the panel’s cabinet
with the PE rail of the power distributon panel from which the fire alarm system will be
powered.
S
Control panels and visual indicators mounted on a wall should be installed at a height of 800 to
1800 mm above the floor.
S
The fire alarm system is not suited for connection to IT power supply systems.
!
Danger – Electrical shock !
Remove all power from the panel before carrying out any installation work!
ESD protection
While handling electronic assemblies, the necessary precautions against electrostati
c
discharge must be taken.
Protective and functional earth
The PE conductor must be connected to the corresponding terminal at the mains supply
.
Connect the FE terminal of the panel’s cabinet with the PE rail of the power distributo
r
panel from which the fire alarm system will be powered.
Installation Instruction
s
