Fire Alarm Computer 8000C / M
4.1.3 Info text / additional text and parameter display
1. FIRE Zone : 002 Det : 02 15:10 28:07
Office 1 Room 17 1st floor
Access via stairway right
Inform Mr. J. Smith (Tel. 02137 / 99152)
2
1
Status Param/*T
Fig. 14: Info text display

Info
Display of any programmed information text relating to the message in the
alphanumeric display. If information text exists, i.e. has been programmed for
this message, the menu point Info is displayed. If info text has not been
programmed, the menu point Info is not displayed.

Param/AT
Display of the additional text programmed for the current message or a
parameter. For a parameter, a works-programmed information text for the
current message in the alphanumeric display is shown. It is possible to switch
between additional text/parameter display using the function key. If additional
text has not been programmed, the menu point Add. text is not displayed.
If information or additional text and a parameter have been programmed for a message, the
information and additional text is always displayed first. Pushing the Param./AT function key during
the display of the additional text shows the parameter.
Example of an info text display (Fig. 14)
Access to programmed information text for this message programmed in the customer data and
related to the zones (max. 4 lines / 40 characters per line) can be attained by pressing the function
key Info.
In this example, the following two-line info text was programmed for detector zone 02 in a fire
condition:
Access via stairway right !
Inform Mr. J. Smith (Tel. 02137/ 99152)
Info text / additional text and parameter display
☞
Pressing the Condition function key returns the panel to the condition display. The display
switches automatically to the preceding menu point approx. 20 sec. after the last operation.
