Fire Alarm Computer 8000C / M
Page 67
8.2 Central housing
1. Remove the central housing of the FACP 8000C / M from the box.
The cover contact and both connecting cables for the rechargeable batteries have already
been attached to the basic module.
2. Pull the ribbon cable of the operating module and of the built-in printer (if present) off the
connectors of the basic module.
3. Remove the four connecting screws between the base plate and the housing frame which were
screwed in for transport.
4. The housing door (operating module and variants) has already been connected to the housing
frame at the factory. To detach the housing door from the housing frame, pull out both
retaining pins of the housing door holder.
5. The housing must be mounted on a stable, clean and dry wall surface without mechanical
stress. The function of the snap-type connection for the housing door can be impaired if the
housing is not correctly mounted.
Only flat-head screws and dowels with a diameter of 8 mm should be used to secure the
central unit’s housing.
Here, make sure that the screw head fits into the hole of the wall compensation element and
does not project.
6. To compensate for slight wall unevenness, you can screw the four wall compensation pieces of
the base plate in or out.
The central unit’s additional pack contains a special spanner for the adjusting the wall
compensation elements.
The three unused fastening points between the base plate and the housing frame are not
necessary on the FACP 8000C / M. This fastening is intended for a different housing use.
The basic module terminals could be removed for easy installation. Disconnection of already wired
terminals is not necessary.
Danger - Electrical shock !
Disconnect all power from the panel before carrying out any installation work. The pane
may only be operated while the cabinet is closed. Operation is not allowed while th
cabinet is open, or if the housing is not fully assembled or if cabinet openings have bee
tampered with.
Risk of short circuit
All voltage and signal lines connected to the basic module must be secured to preven
slipping by using a suitable attachment materials such as plastic cable binders. Work o
the fire alarm central unit 8000C may only be carried out when it is deenergized (main
and emergency power supply).
