Page 94
Fire Alarm Computer 8000C / M
11 Field device module
There are two different kinds of field device module available for the FACP 8000C / M.
1) Field device module with one micro module slot (Part no. 772418)
2) Field device module (Part no. 772420)
The field device module integrates all of the input and output modules that are necessary in
addition to the modules on the basic module for the FACP 8000C to operate as a fire alarm control
panel to DIN VDE 0833.
An fire alarm control panel 8000C / M will accommodate a field device card for connecting a fire
department operating panel and a master box. Three freely programmable relays are also
provided for any output function that may be required. Coding bridges (BR9- BR20) may be used
for setting the activation mode for these three relays (K2, K3, K4) to monitored and positive-
switching, positive-switching or as a potential-free change-over contact. The coding bridges (BR3-
BR5) may also be used for setting these relays to activate if an event occurs while the control
panel is in the CPU failure mode.
If a control panel is required to function in accordance with DIN 0833, you should program the
relays with the
common fire (K2)
,
common alarm (K3)
and
common disconnection (K4)
in the customer
data of the control panel.
☞
On leaving the factory, only relay K1 is configured to activate the master box in CPU failure
mode.
Do not connect relays (AE) of the FACP 8000C/M with alternating voltage. Even in the cas
of a
potential free relay
mode it is not possible to switch an external AC-voltage
ield device module
