Fire Alarm Computer 8000C / M
23 esserbus
®
transponder
esserbus
®
transponders are input/output modules for extending the control panel inputs/outputs.
As devices on the analog loop - the esserbus
®
- they may be operated jointly in separate detector
zones with fire detectors on the esserbus
®
.
It is possible to install up to 32 esserbus
®
transponders in separate detector zones (separated by
zone isolators). Mixing the operation of fire detectors and esserbus
®
transponders is not
permissible within one detector zone.
The esserbus
®
transponders is installed either at special fitting locations or on a standard C-
mounting rail in the fire alarm control panel, or at decentralised level at any location in the analog
loop in a special plastic housing (part No. 788600 / 788601). The internal voltage supply is fed to
the esserbus
®
transponder from the zone voltage of the analog loop.
The following esserbus
®
transponders are available at present:
Part no.
1)
Type Designation
esserbus
®
esserbus
®
-PLu
s
eK-12REL with 12 relay outputs
78
8610 /
80
8610
80
8610
eK-32AE with 32 outputs to drive LED
78
8611 /
80
8611
80
8611
eK-1Gruppe with one detector zone input
78
8614 /
80
8614
80
8614
eK-4Grp/2Rel with 4 detector zone inputs and 2 relay
outputs or a BSL interface for
controlling extinguishing systems
78
8613 /
80
8613
80
8613
eK-KOM-LMST communications transponder for a
8010 fire alarm and extinguishing
computer.
This communications transponder is
installed inside the housing and
immediately on the processor board o
f
the 8010 fire alarm and extinguishing
computer.
78
8615 /
80
8615
80
8615
eK-FSA The FSA-transponder for a stand-
alone fire door control or as a loop
device connected fire alarm system
8000.
80
8619
Third party
module RZT
8000
For an individual connection of
automatic and non-automatic fire
alarm detectors supplied by other
manufacturers
80
863X
1)
For esserbus
®
-PLus loops with a loop voltage of 42 V it is required to connect the appropriate transponders or
devices with the part-no. 80xxx x (refer to section "esserbus
®
-PLus function ").
