Fire Alarm Computer 8000C / M
13 3-relay module / 3-relay common trouble module
Micromodule for activating external devices (not potential free) such as a flashing lamp or siren,
with monitoring capability. You may connect up to three external devices to this micromodule.
W i t h t h e 3 - r e l a y m o d u l e ( 7 8 7 5 3 2 ) , r e l a y K 1 i s c o n n e c t e d
a s c o m m o n t r o u b l e r e l a y , t h a t i s , i n t h e n o r m a l a c t i v a t e d .
X 1
N O N C N O N C
S 2
1 2
S 1
K 3
K 2
F 5 F 3
K 1
F 1
T E S T
L E D
1
2
3 4 5 6 7 8 9 1 0
7 8 7 5 3 1 3 R Ü 7 8 7 5 3 2 3 R Ü S
3 - r e l a y m o d u l e / 3 r e l a y c o m m o n t r o u b l e m o d u l e
X 1
64-way plug connector to micro module slot of the basic module, field device module
or extension module of the FACP 8000C / M
Relay
K 1 (for 3-relay common trouble module type used as common trouble relay)
K 2 and K 3 freely programmable, max. contact rating 30 V DC /1 A
S1, S2
coding switch for selecting monitored / non- monitored setting, or for special
application
TEST
Test socket only. For in-factory adjustments!
LED
No indicator function (in-factory testing purposes)
F1, F3, F
5
Electronic fuse (multifuse): to reset, de-energize for approx. 30 seconds at the
relevant screw terminals on the terminal card
!
No AC voltages may be applied to the relays built-into the 8000C / M FACP. This applie
s
also to those relays operated in the
non-monitored
mode.
Relay assignment is programmed with the service PC and Customer Data Editor 8000C / M
software. For each relay, you may enter a specific additional text comprising 25 characters per line
for output on the alphanumeric display and protocol printer
3
-relay module / 3-relay common trouble module
