Fire Alarm Computer 8000C / M
Page 77
Primary loop number (Panel no. 01)
Basic module (Panel no. 01)
Primary loo
p
number
subassembly
0111 common fault relay of the basic module
0112 interface of the basic module
0113 micro module slot of the basic module
Field device module in
slot 1
(panel no. 01)
Primary loo
p
number
subassembly
0121 relays K2, K3 and K4 of the field device module
0122 Relay K1 of the field device module
0123 micro module slot of the Field device module
0124 internal primary loop of the Field device module
Extension module 772419 in
slot 1
Primary loop
number
subassembly
0121
no module available
0122
no module available
0123 micro module slot of the extension module
0124
no module available
Extension module 772421 in
slot 1
(only FACP 8000M)
Primary loop
number
subassembly
0121 micro module slot No. 1 of the extension module
0122 micro module slot No. 2 of the extension module
0123 micro module slot No. 3 of the extension module
Extension module 772421 in
slot 2
(only FACP 8000M)
Primary loop
number
subassembly
0131 micro module slot No. 1 of the extension module
0132 micro module slot No. 2 of the extension module
0133 micro module slot No. 3 of the extension module
☞
Peripheral modules or extension modules may only be installed in
slot 1
of the basic
module.
Slot 2
of the basic module is unused on the 8000C FACP.
Location of plug in card
s
