Page 96
Fire Alarm Computer 8000C / M
Relay K1
Relay for connecting a master box. May also be used as a freely programmable
relay.
Selection of operating mode and emergency function by means of jumpers.
(Monitoring range 50
Ω
to 1 k
Ω
)
Contact rating when used as a
non-monitored change-over contact
< 30 V DC/
max.1 A
Relay K2,3,4
Relay with common function. May also be used as a freely programmable relay.
Selection of operating mode and emergency function by means of jumpers.
Contact rating when used as a
non-monitored change-over contact
< 30 V DC/
max.1 A
8 inputs for connecting a fire department operating panel
X4
8 outputs for connecting a fire department operating panel
X5
Connection terminals for (master box relay, K1)
for connecting the master box supply voltage, inc. confirmation input for verifying
master box activation
X6
Connection terminal for relay K2
X7
Connection terminal for relay K3
X8
Connection terminal for relay K4
X9 / GR1
Internal primary line input (XX24, XX= FACP number)
normal operation
→
R = 10 k
Ω
fire alarm
→
R
≤
5 k
Ω
F1 to F4
Fuses for the four relays (T 1A)
V8, V10,
V11, V12
The LED lights while the corresponding relay is activated or when is has been
programmed for inverse control in the customer data programming.
V20 to V22
yellow LED V 20 will light up when the fire alarm control panel is operating in
CPU failure mode
green LED V 21 will light up when the cover contact (control panel housing)
is open
red LED V 22 will light up if a fire alarm is detected while the control pane
is operating in CPU failure mode
BR1 and BR2
Solder bridges for setting the master box control in emergency operation
BR3 to BR5
Jumpers for setting the CPU failure mode function for relays K2, K3, K4
BR6 to BR20
Jumpers for setting the operating mode of the master box relay and the three
freely programmable relays K2, K3, K4
BR21
Coding jumpers for the FDOP connector with
fire event control out.
(Terminals X4/IN8)
Jumper in position 1-2
→
fire event control out
not connected
Jumper in position 2-3
→
fire event control out
connected (factory setting)
ield device module
