156 Chapter 13 Submasters
Submaster LEDs
Each submaster bump button contains an LED. The state of the LED
indicates the current state of that submaster, as shown in the chart below:
If the LED on a slider is blinking slowly, it means that you have changed
pages and a new submaster is waiting to load. The old submaster stays
loaded until you move the slider to the home position. When the slider
reaches home, the channel levels from the new page replace the old
levels.
Note: If a submaster slider has both a submaster loading and a submaster
on hold, the submaster on hold takes priority and the LED blinks fast.
Press the bump button to downfade the old submaster.
Color State Meaning
–– Off Submaster not loaded.
Green Solid Submaster loaded.
Green Slow Blink New submaster. Loads when slider reaches home
position.
Green Fast Blink Submaster on timed hold. Press bump button to
begin downfade.
