280 Chapter 25 Control interfaces
MIDI Message definitions
Submaster bump switch execution
Submasters 1 - 12 C5 - B5 #60 - #71
Submasters 13 - 24 C6 - B6 #72 - #83
Note: C5 = MIDI note #60 or middle C.
Cue execution in AB fader pair
Next cue Program change 0
Cues 1 - 127 Program change 1 - 127
Cues 128 - 255 Controller change 70, parameters 0 - 127
Cues 256 - 383 Controller change 71, parameters 0 - 127
Cues 384 - 511 Controller change 72, parameters 0 - 127
Cues 512 - 639 Controller change 73, parameters 0 - 127
Cues 640 - 767 Controller change 74, parameters 0 - 127
Cues 768 - 895 Controller change 75, parameters 0 - 127
Cues 896 - 999 Controller change 76, parameters 0 - 103
Cue execution in CD fader pair
Next cue Controller change 77, parameter 0
Cues 1 - 127 Controller change 77, parameters 1- 127
Cues 128 - 255 Controller change 78, parameters 0 - 127
Cues 256 - 383 Controller change 79, parameters 0 - 127
Cues 384 - 511 Controller change 80, parameters 0 - 127
Cues 512 - 639 Controller change 81, parameters 0 - 127
Cues 640 - 767 Controller change 82, parameters 0 - 127
Cues 768 - 895 Controller change 83, parameters 0 - 127
Cues 896 - 999 Controller change 84, parameters 0 - 103
Macro execution
Macros 1 - 127 Controller change 85, parameters 1 - 127
Macros 128 - 255 Controller change 86, parameters 0 - 127
Macros 256 - 383 Controller change 87, parameters 0 - 127
Macros 384 - 511 Controller change 88, parameters 0 - 127
Macros 512 - 639 Controller change 89, parameters 0 - 127
Macros 640 - 767 Controller change 90, parameters 0 - 127
Macros 768 - 895 Controller change 91, parameters 0 - 127
Macros 896 - 999 Controller change 92, parameters 0 - 103
Level change wheel
Pitch bend value Message values
Wheel “ticks”
(hexadecimal) (decimal)
0 2000 ll=0 mm=64
+1 2001 ll=1 mm=64
-1 1FFF ll=127 mm=63
+8191 (+12.5%) 3FFF ll=127 mm=127
-8192 (-12.5%) 0 ll=0 mm=0
+655 (+1%) 228F ll=15 mm=69
-655 (-1%) 1D71 ll=113 mm=58
