Table 4-2. Center Cross
Aspect Ratio
4 : 3 16 : 9
Line System Line System
625 525 625 525
Overscan indication
•
Horizontal/vertical direction alternating black / white border
Position of border castellations
•
Horizontal direction 2% / 3%
of active line
2% / 3%
of active line
2% / 3%
of active line
2% / 3%
of active line
Border castellations 2% / 3%:
Parameter 1
Parameter 2
10.5/ 10.5 µs
11.6/ 12.1 µs
9.2/ 9.2 µs
10.2/ 10.7 µs
10.5/ 10.5 µs
11.6/ 12.1 µs
9.2/ 9.2 µs
10.2/ 10.7 µs
Parameter 4
Parameter 5
61.5/ 61.0 µs
62.5/ 62.5 µs
61.0/ 60.5 µs
62.1/ 62.1 µs
61.5/ 61.0 µs
62.5/ 62.5 µs
61.0/ 60.5 µs
62.1/ 62.1 µs
•
Vertical direction 2% / 3%
of active field
2% / 3%
of active field
2% / 3%
of active field
2% / 3%
of active field
Border castellations 2%:
Line a: 1. field / 2. field
Line b, 1. field /.2 field
Line d, 1. field / 2. field
Line e, 1. field / 2. field
line 23/ 336
line 28/ 341
line 305/ 618
line 310/ 623
line 21/ 283*
line 25/ 287*
line 259/ 521*
line 263/ 525*
line 23/ 336
line 28/ 341
line 305/ 618
line 310/ 623
line 21/ 283*
line 25/ 287*
line 259/ 521*
line 263/ 525*
Border castellations 3%:
Line a: 1. field / 2. field
Line b, 1. field /.2 field
Line d, 1. field / 2. field
Line e, 1. field / 2. field
line 23/ 336
line 31/ 343
line 303/ 615
line 310/ 623
line 21/ 283*
line 27/ 290*
line 256/ 519*
line 263/ 525*
line 23/ 336
line 31/ 343
line 303/ 615
line 310/ 623
line 21/ 283*
line 27/ 290*
line 256/ 519*
line 263/ 525*
Position of center cross
•
Horizontal line, line c,
1. field / 2. field line 167/ 479 line 142/ 404* line 167/ 479 line 142/ 404*
•
Vertical line,
Parameter 3 36.52
µ
s 35.63
µ
s 36.52
µ
s 35.63
µ
s
*subtract 3 lines for PAL M
Applications:
Center Cross is ideal to center TV monitors and TV screens and alignment of picture
height/picture width. Furthermore, it is used to check the deflection linearity and the pin-
cushion correction. Overcan indications allow precise adjustment of the wanted picture
size. Blurred shown vertical lines point to a bad frequency response and multiple lines
may be the result of reflections.
