Remote Control
Remote Control Commands
6
6-17
Internal Operations
*RST Reset Command
This command performs a reset, which sets the instrument to a default status:
Table 6-2. Instrument Default Settings after Reset (*RST)
For instruments with PAL with or without NTSC and/or SECAM:
Country None Pattern DIGI_ADC2
TV Standard PAL B/G Aspect Ratio 4:3
Vision Carrier 471.25 MHz Sound System FM mono
RF Level 10.0 mV Sound Mode Mono
Residual Carrier LOW (10%) Sound Carrier 1 5.5 MHz
Group Delay ON Sound Carrier 1 Level -13 dBc
Video Amplitude 100% Preemphasis ON (50 µs)
Chroma Amplitude 100% Sound Mod. Frequency 1 kHz
Video Source Intern Teletext Auto
Video Output CVBS Text Lines 8
Video Sync OFF WSS Auto
Video Polarity Positive VPS/PDC Set 7 / Set 7
Different settings for instruments with NTSC, without PAL, with or without SECAM:
TV Standard NTSC M Preemphasis ON (75 µs)
Sound Carrier 1 4.5 MHz Closed Caption CC Number 1
Sound Carrier 1 Level -10 dBc Teletext OFF
Different settings for instruments with SECAM, without PAL and without NTSC:
TV Standard SECAM L Frame Indication OFF
Group Delay OFF Teletext A OFF
Sound System AM L Text Lines 4
Sound Carrier 1 6.5 MHz WSS Auto
Sound Carrier 1 Level -10 dBc VPS OFF
Preemphasis None
All parameters not mentioned are set according to PAL B/G and the sound system
FM Mono.
The reset does not affect the internal memories, for instrument settings, the PDC and VPS data
sets, the enable registers, and the status registers of the interface.
