54200
Users Manual
5-16
WSS Auto Mode
The WSS information corresponds with the actual instrument settings. For details, see
table below. WSS data bits of the WSS Auto mode are not displayed by the instrument.
Table 5-6. WSS Auto Mode
Data Group WSS Bits Instrument settings
Group 1,
Aspect Ratio
Bit No.
0 1 2 3
Full format 4:3
Full format 16:9 (anamorphic)
0 0 0 1
1 1 1 0
with all 4:3 patterns
with all 16:9 patterns
Group 2,
Enhanced Services
Bit No.
4 5 6 7
Camera Mode bit 4 = 0 with following patterns:
Moving Block
Progressive Scan Check 1 to 3
Film Mode bit 4 = 1 with all non-camera mode patterns
Standard PAL / SECAM bit 5 = 0 always
No Helper bit 6 = 0 always
Reserved bit bit 7 = 0 always
Group 3,
Subtitles
Bit No.
8 9 10
No subtitles within teletext
Subtitles within teletext
bit 8 = 0
bit 8 = 1
no teletext signal is generated
teletext signals are generated
No subtitles in active image area bit 9/ 10 = 0 no OSD function is used
Group 4,
Reserved
Bit No.
11 12 13
Surround sound signalling bit:
No surround information
Surround mode
bit 11 = 0
bit 11 = 1
no Stereo signal is generated
Stereo signals are generated
Reserved bits bit 12 = 0
bit 13 = 0
always
always
