Pattern Popup Menus
G
G-3
Center Cross
Off
Center_2%
Center_3%
Demodulation Test
Off
DEM_PAT1
DEM_PAT2
Dots
Off
Dots_White
Dots_Black
Purity
Off
PUR_White
PUR_Yellow
PUR_Cyan
PUR_Green
PUR_Red
PUR_Magenta
PUR_Blue
PUR_Black/Off
Crosshatch
Off
CH_White
CH_White_C
CH_White_TL
CH_White_C_TL
CH_Black
CH_Black_C
CH_Black_TL
CH_Black_C_TL
Color Bar
Off
COL_100_25
COL_75_25
COL_100_0
COL_75_0
COL_SMPTE
COL_Horz
COL_SP_100
COL_SP_75
625 Line Systems
White
Off
White_0%
White_5%
White_15%
:
in 5% steps to
:
White_90%
White_95%
White_100%
525 Line Systems
White
Off
White_7.5IRE
White_15IRE
White_20IRE
:
in 5IRE steps to
:
White_90IRE
White_95IRE
White_100IRE
