Specifications
925
Appendix
23
HCF B1 (optional)
HCF B1-S (optional)
Paper Weight 64 - 300 gsm
Note •221 - 300 gsm size paper can be used as white
cover sheets for center binding/center folding
only when printing (White cover sheets cannot
be used when copying).
Folding
Important • When the D4/D5 Folder Unit is
installed.
z
Z-Fold
Paper Size: A3, B4, 11 × 17"
Paper Weight: 64 - 90 gsm
z
C-Fold
Paper Size: A4 , Letter
Paper Weight: 64 - 90 gsm
Inserter Paper Size Maximum: A3, 11 × 17"
Minimum: B5
Important •You cannot print on the paper loaded in the
Inserter.
Paper Weight 64 - 220 gsm
Capacity 200 sheets
Important •When using FX P Paper.
Power Supply AC 100 - 240V ± 10%, 2.03 A - 0.85 A (with Folder
Unit) for both 50/60 Hz ± 3%
Maximum Power Consumption 203 W or less (with Folder Unit )
Dimensions Width 1,055 × Depth 727 × Height 1,165 mm
When Folder Unit is installed:
Width 1,255 × Depth 727 × Height 1,165 mm
Weight 150 kg
(When Folder Unit is installed:190 kg)
Paper Size
z
Standard Size
Maximum: A4, Letter
Minimum: B5
Paper Weight 64 - 220 gsm
Note • It is recommended to use papers recommended by Fuji Xerox.
Paper Capacity / Number
of Trays
2,100 sheets × 1 tray
Note • When using FX J Paper.
Dimensions Width 389 × Depth 610 × Height 377 mm
Weight 29 kg
Paper Size
z
Standard Size
Maximum: A3, 11 x 17"
Minimum: Postcard
z
Non-Standard Size
100 (Y direction) × 148 (X direction) mm - 330 (Y direction) × 488 mm (X
direction)
Note • The Post Card Kit is required to load postcards or non-standard size
paper whose length is 100 - 181 mm (Y direction).
To Next Page
