23 Appendix
926
Appendix
23
High Capacity Feeder C3-DS (optional)
Interface Module (optional)
High Capacity Stacker (optional)
Paper Weight 52 - 300 gsm
Note • It is recommended to use papers recommended by Fuji Xerox. For
using paper manufactured other than by Fuji Xerox, contact our
Customer Support Center.
Paper Capacity / Number
of Trays
2,100 sheets × 1 tray
Important • When using FX J Paper.
Power Supply AC 220 - 240V±10%/100-120V±10%, 1.5A/2.5A for both 50/60Hz±3%
Maximum Power
Consumption
360 W or less
Dimensions Width 988 × Depth 762 × Height 992 mm
Weight 190 kg
Note • When Tray 5 (Bypass) and the Large Size Color Panel are installed.
Paper Size
z
Standard Size
Maximum: A3, 11 x 17"
Minimum: Postcard
z
Non-standard Size
98 (Y direction) × 148 (X direction) mm - 330 (Y direction) × 488 (X
direction) mm
Note • The Post Card Kit is required to load postcards or non-standard size
paper whose length is 98 - 181 mm (Y direction).
Paper Weight 52 - 350 gsm
Note • It is recommended to use papers recommended by Fuji Xerox. For
using paper manufactured other than by Fuji Xerox, contact our
Customer Support Center.
Paper Capacity / Number
of Trays
2,100 sheets × 2 trays
Note • When using FX J Paper.
Power Supply AC 200 - 240V±10%/100-120V±10%, 4A/6A for both 50/60Hz
Maximum Power
Consumption
800 W or less
Dimensions Width 988 × Depth 762 × Height 992 mm
Weight 245 kg
Note • When Tray 5 (Bypass) and the Large Size Color Panel are installed.
Power Supply AC 100 - 240V±10%, 2.5 - 1.5 A for both 50/60Hz ±3%
Maximum Power
Consumption
360W or less
Dimensions Width 345 × Depth 725 × Height 992 mm
Weight 50 kg
Stacker Capacity Stacker Output Tray: 500 sheets
Stacker Tray: 5,000 sheets
Note • When using FX P Paper.
