Fujitsu 8FX User Manual

MB95630H Series
216 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 14 LIN-UART
14.5 LIN-UART Baud Rate
■ Reload Value and Baud Rate of Each Clock Speed
Table 14.5-1 shows the reload value and baud rate of each clock speed.
The unit of frequency deviation is %. MCLK represents machine clock.
Table 14.5-1 Reload Value and Baud Rate
Baud rate
8 MHz (MCLK) 10 MHz (MCLK) 16 MHz (MCLK) 16.25 MHz (MCLK)
Reload
value
Frequency
deviation
Reload
value
Frequency
deviation
Reload
value
Frequency
deviation
Reload
value
Frequency
deviation
2M −−4070−−
1M7090150−−
500000 15 0 19 0 31 0 −−
400800 −−−−−−−−
250000 31 0 39 0 63 0 64 0
230400 −−−−68 - 0.64 −−
153600 51 - 0.16 64 - 0.16 103 - 0.16 105 0.19
125000 63 0 79 0 127 0 129 0
115200 68 - 0.64 86 0.22 138 0.08 140 - 0.04
76800 103 0.16 129 0.16 207 - 0.16 211 0.19
57600 138 0.08 173 0.22 277 0.08 281 - 0.04
38400 207 0.16 259 0.16 416 0.08 422 - 0,04
28800 277 0.08 346 - 0.06 555 0.08 563 - 0.04
19200 416 0.08 520 0.03 832 - 0.04 845 - 0.04
10417 767 < 0.01 959 < 0.01 1535 < 0.01 1559 < 0.01
9600 832 - 0.04 1041 0.03 1666 0.02 1692 0.02
7200 1110 < 0.01 1388 < 0.01 2221 < 0.01 2256 < 0.01
4800 1666 0.02 2082 - 0.02 3332 < 0.01 3384 < 0.01
2400 3332 < 0.01 4166 < 0.01 6666 < 0.01 6770 < 0.01
1200 6666 < 0.01 8334 < 0.01 13332 < 0.01 13541 < 0.01
600 13332 < 0.01 16666 < 0.01 26666 < 0.01 27082 < 0.01
300 26666 < 0.01 −−53332 < 0.01 54166 < 0.01
