MB95630H Series
218
FUJITSU SEMICONDUCT
OR LIMITED
MN702-00009-2v0-E
CHAPTER 14 LIN-UAR
T
14.5 LIN-UAR
T Baud Rate
â–
Operation of Dedica
ted Baud Rate Generator (Reload Counter)
Figure
14.5-2 shows the operation of t
wo reload count
ers using a reload val
ue "832" as
an
example.
Figure
14.5-2 Operatio
n of Dedicated Baud Rate Gen
erator (Reload Counter)
Note:
The falling edge of the serial cl
ock signal is generated after
the reload value divided by 2
[(V+1)/2] is counted.
T
ransmit/receive cloc
k
Reload counter
Reload counter value
002
001
832
831
830
829
828
417
416
415
414
413
412
411
F
alling at (V+1)/2
239
241
