MB95630H Series

MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 577

CHAPTER 26 DUAL OPERATION FLASH MEMORY

26.8 Registers

Figure 26.8-12 FSR4:CEREND during Chip Erase

FSR:RDY

FSR3:CERS

FSR3:SERS

FSR4:CEREND

Chip erase

command

Chip erase

end
