174 Upgrade and Maintenance Manual TX140 S1
Hard disk drives / solid state drives
SAS / SATA connectivity
HDD naming scheme
Controller Channel Connection
Onboard SATA
controller
1
Drives 1-4
SAS / SATA cable (Y3963-V101) from
HDD backplane connector X1 to system
board connector SATA MLC 1.
PCI SAS controller 1
Drives 1-4
SAS / SATA cable (Y3963-V101) from
HDD backplane connector X1 to PCI
SAS controller
3.5-inch HDDs
Bay
RAID
Manager
#
Channel
log.
Drive #
Bay
RAID
Manager
#
Channel
log.
Drive #
1 [0] 103[2] 12
2 [1] 114[3] 13
Table 6: HDD naming scheme
