TX140 S1
Upgrade and Maintenance Manual
583
Appendix
17.3.2
Conn
ectors and indicators on the front p
anel
17.3.2.1
Front panel connectors
Figure 407: Front panel conne
ctors
Pos.
Component
Reference
1
optional VG
A connector
(not used)
2
optional front LAN connector
"Replacing the front LAN
connector and board" on page
408
3
front USB connectors
582
584
