TX140 S1
Upgrade and Maintenance Manual
523
Cabling
16.4
Replacing the
ODD SA
T
A cable
Figure 355: ODD
SA
T
A
cable T26139-Y3928-V
205
16.4.1
Required too
ls
●
Preliminary and concludi
ng steps: tool-less
●
Replacing the ODD SA
T
A cable: tool-less
Field Replaceable Unit
s (FRU)
A
verage task duration: 10 minutes
522
524
