TX140 S1 Upgrade and Maintenance Manual 529
Cabling
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 90.
Ê If applicable, close the rack door as described in section "Closing the rack
door" on page 92.
16.5 Replacing SAS / SATA backplane cables
Figure 360: SAS / SATA backplane cable T26139-Y3963-V101
16.5.1 Required tools
Preliminary and concluding steps: tool-less
Replacing the SAS / SATA backplane cable: tool-less
Field Replaceable Units (FRU)
Average task duration: 10 minutes
