TX140 S1 Upgrade and Maintenance Manual 367
Accessible drives
12.4.5 Replacing a backup drive
Ê Remove the defective backup drive as described in section "Removing a
backup drive" on page 356.
Figure 219: Removing EasyClick rails (example: RDX backup drive)
Ê Remove two screws from each side of the defective backup drive to detach
the EasyClick rails.
Figure 220: Attaching EasyClick rails to the backup drive (RDX)
