Fujitsu PRIMERGY TX140 S1 Upgrade And Maintenance Manual

378 Upgrade and Maintenance Manual TX140 S1
Front panel and external connectors
13.1.4 Installing the front panel module
Ê If the front LAN connection is to be installed in the new front panel module,
install the front LAN cable as described in section "Preparing the front panel
module" on page 386.
Figure 228: Connecting the front panel cable
Ê Connect the front panel cable to the new front panel module as shown.
