TX140 S1 Upgrade and Maintenance Manual 545
Cabling
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 90.
Ê If applicable, close the rack door as described in section "Closing the rack
door" on page 92.
16.7 Replacing the front LAN cable
Figure 374: Front LAN cable T26139-Y4025-V1
Ê Please proceed as described in section "Replacing the front LAN connector
and board" on page 408.
Field Replaceable Units (FRU)
Average task duration: 10 minutes
