TX140 S1 Upgrade and Maintenance Manual 301
Main memory
Ê Open the side / top cover as described in section "Removing the top cover"
on page 67 (rack server) or "Removing the side cover" on page 71 (tower
server).
Ê Remove the fan module as described in section "Removing the fan module"
on page 208.
10.3.3 Removing a memory module
Ê Identify the desired memory slot according to the mounting order described
in section "Memory sequence" on page 294.
V CAUTION!
Ensure to maintain an operational configuration when removing
memory modules. For additional information, please refer to section
"Operation modes" on page 295.
Figure 166: Removing memory modules (A)
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory module connector.
