Hard disk drives / solid state drives
HDD / SSD naming scheme
I The HDD / SSD numbering as listed in the ServerView RAID Manager
differs from the HDD mounting order:
7.2.2 Installing 2.5-inch HDD / SSD modules
7.2.2.1 Required tools
● Preliminary and concluding steps: tool-less
● Installing a 2.5-inch HDD / SSD module: tool-less
2.5-inch HDDs / SSDs
Bay
RAID
Manager
#
Channel
log.
Drive #
Bay
RAID
Manager
#
Channel
log.
Drive #
1 [0] 102[4] 20
3 [1] 114[5] 21
5 [2] 126[6] 22
7 [3] 138[7] 23
Table 5: HDD naming scheme
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
